2U Rack Mount Enclosures — Aluminum Chassis

The primary chassis material is 0.125-inch thick aluminum sheet, Alloy 6061-T6, per federal specification QQ-A-250/11 and ASTM B209. Handles use extruded aluminum Alloy 6061-T5, and accessories such as angle brackets use Alloy 5052-H32, all selected for strength-to-weight ratio and machinability.

The standard finish is Chemical Film per MIL-C-5541E, Type 1, Class 3 (gold). Handle hardware receives a black anodize finish per MIL-A-8625E, Class 2, Type 2. A flat grey painted front panel finish per LLNL Specification LED 67-9092 is also available for laboratory and government applications.

Ron Nunes offers depths of 8, 14, 20, and 26 inches as standard options. Custom depths are available upon request to accommodate non-standard equipment or specific installation constraints in mobile, field, or fixed-rack deployments.

Chassis systems are shipped unassembled as standard, including all required components — front panel, rear panel, two side brackets, two covers, handles, and fastening hardware. Fully assembled systems are available upon request, with assembly performed by Class A/XX certified welders and assemblers.

Standard stock items in matt finish are available and can ship within one week. Custom chassis components and modules carry a lead time of approximately 15 working days. Contact Ron Nunes directly at 1-877-800-RACK or via the online request form for specific availability and scheduling details.

Yes. Ron Nunes offers custom chassis component and module design for OEM integrators, defense contractors, and government laboratories. Custom work is executed by Class A/XX certified welders and includes MIL-spec finish options. Prototypes through full production runs are supported, and engineering assistance is available upon request.
